Brooks Automation 001-4130-03 | VCE Controller / Wafer Alignment Controller
Product Introduction
In semiconductor equipment, a controller failure can stop an otherwise functional wafer-handling subsystem because the controller sits between motion hardware, sensors, and the equipment-level control sequence. The Brooks Automation 001-4130-03 is identified in equipment-spare records as a VCE Controller, associated with precision wafer-handling and alignment functions. Its role is not comparable to a conventional PLC CPU or general-purpose industrial I/O module.
The Brooks Automation 001-4130-03 should therefore be purchased against the exact equipment configuration rather than by generic controller specifications. Available records associate the part with wafer alignment and VCE equipment, while some secondary listings provide substantially different electrical and communications data. Those unverified values should not be used as the design basis for a semiconductor-tool retrofit.
Key Technical Specifications
| Parameter | Verified / Recommended Procurement Description |
|---|---|
| Product Model | 001-4130-03 |
| Manufacturer | Brooks Automation |
| Product Type | VCE Controller |
| Functional Category | Wafer handling / alignment control |
| Primary Application | Semiconductor manufacturing equipment |
| Control Function | Precision equipment and wafer alignment control |
| Associated Equipment | Brooks VCE equipment |
| Part Description | VCE Controller – Repair |
| Communication Interface | Verify from equipment configuration |
| Input Voltage | Verify from nameplate/manual |
| Operating Temperature | Verify from equipment documentation |
| Dimensions | Verify actual hardware |
| Firmware | Verify installed revision |
| Condition | Verify actual inventory condition |
The identification as VCE Controller is supported by spare-parts records, including a GetSpares record that explicitly describes 001-4130-03 as “VCE CONTROLLER – REPAIR.”
Several secondary listings instead describe the part as a wafer alignment controller and provide specifications such as 24 VDC, RS-232/RS-485/Ethernet, or particular positioning accuracy. Those claims are inconsistent across sources and are not sufficiently documented to present as confirmed specifications.
Major Features and Engineering Advantages
VCE Equipment Control
The important characteristic of the 001-4130-03 is its role within Brooks semiconductor equipment. Available records identify it as a VCE controller rather than a standard catalog PLC module. That distinction matters during troubleshooting because replacement compatibility depends on the equipment architecture, firmware, connected motion hardware, and controller configuration.
001-4130-03
Wafer Alignment and Handling
Secondary equipment records associate the controller with wafer alignment operations, including precision positioning and alignment functions. These descriptions are consistent with its identification as a VCE controller used in semiconductor equipment, although exact axis count and feedback architecture should be confirmed against the machine documentation.
Legacy Equipment Support
The 001-4130-03 is primarily relevant when maintaining existing semiconductor equipment rather than designing a new general-purpose automation system. That makes revision matching especially important. A physically similar controller with a different firmware or hardware revision may not initialize correctly with the installed equipment.
Equipment-Specific Replacement
The practical value of this part is its compatibility with the original equipment architecture. For semiconductor-tool maintenance, that can be more important than generic specifications such as processor speed or nominal communication interface.
Application Scenarios & Pain Points
Semiconductor Wafer Handling
The controller is associated with Brooks wafer-handling equipment where motion and alignment functions must operate as part of a larger automated material-transfer sequence.
Wafer Pre-Alignment
Secondary records specifically associate the 001-4130-03 with wafer alignment functions. The exact sensing and servo arrangement should be confirmed against the machine model before assuming compatibility.
Legacy Semiconductor Equipment Maintenance
When an original controller fails, the replacement must match the installed machine architecture. This is particularly important for older equipment where documentation may be incomplete and replacement controllers may come from different production revisions.
Repair and Spare-Parts Programs
The part is also listed specifically as a VCE Controller – Repair, indicating that repair/refurbishment is part of the secondary spare-parts market surrounding this number. That does not establish the condition of any individual unit, so actual hardware condition must be verified separately.
Field note: Do not purchase this part simply because a supplier describes it as a generic “wafer alignment controller.” Confirm the equipment model, controller revision, connectors, firmware, and the exact label on the existing unit.
Related Products
- 001-4130-01 — Reported as another 001-4130-series controller variant; verify exact equipment compatibility before substitution.
- 001-4130-09 — Reported as another related controller variant; hardware and firmware differences require verification.
- Brooks VCE Controller Assemblies — Related VCE control hardware; exact assembly number should be matched to the machine.
- Brooks Wafer Alignment Equipment — Higher-level equipment using dedicated alignment/control electronics.
- Brooks Pre-Aligner Systems — Related wafer orientation and alignment equipment; not automatically interchangeable with the VCE controller.
The available public records do not provide enough authoritative information to classify these related numbers as direct drop-in replacements. Treat them as reference points only until the equipment documentation confirms interchangeability.
Engineer’s Guide — Field Pitfalls to Avoid
1. Do not treat 001-4130-03 as a conventional PLC module.
It is identified as a VCE Controller, meaning its compatibility is equipment-specific. Generic PLC specifications are not an adequate basis for replacement.
2. Do not trust conflicting online specifications.
One source reports 12 VDC, while another reports 24 VDC; other listings claim different communications interfaces and environmental specifications. That conflict is exactly why those values should not be published as confirmed data.
3. Match the complete part number.
The difference between 001-4130-03 and another 001-4130-series variant may involve hardware, firmware, I/O, or machine compatibility. Do not substitute by prefix alone.
4. Record the installed firmware before replacement.
For semiconductor equipment, controller firmware can be tied closely to the machine-control application. A controller that is electrically compatible may still fail initialization if its software configuration does not match the equipment.
5. Photograph the connectors and nameplate.
For a legacy controller, photographs of the front/rear labels and connector arrangement are often more useful for procurement verification than a generic supplier specification sheet.
6. Verify actual condition.
A listing that describes a part as “new,” “original,” or “refurbished” does not establish the condition of the particular unit being supplied. For a critical semiconductor-tool spare, request serial/revision information and actual hardware photographs.
FAQ
What is Brooks Automation 001-4130-03?
001-4130-03 is identified as a Brooks Automation VCE Controller and is associated with semiconductor wafer-handling and alignment equipment.
Is 001-4130-03 a PLC CPU?
No. Available records identify it as a VCE controller for Brooks semiconductor equipment rather than a general-purpose PLC CPU. Its compatibility should be evaluated within the original equipment architecture.
What equipment does 001-4130-03 work with?
Public records associate the controller with Brooks VCE equipment and wafer alignment/handling applications. Some secondary records associate it with specific wafer-transfer platforms, but those equipment associations should be confirmed against the machine’s own documentation before ordering.
What is the operating voltage of 001-4130-03?
There is no sufficiently consistent public specification to state a definitive operating voltage. Secondary sources conflict, reporting both 12 VDC and 24 VDC. The actual nameplate and equipment manual should therefore be used for electrical verification.
Does 001-4130-03 support Ethernet or RS-485?
Some secondary listings claim RS-232, RS-485, and Ethernet, but these interfaces are not sufficiently corroborated by an authoritative Brooks technical document located for this exact part number. Treat them as unverified until confirmed from the machine documentation or physical controller.
What should be checked before purchasing a replacement?
Verify the complete part number 001-4130-03, hardware revision, firmware, equipment model, connector configuration, electrical supply, and controller configuration. For a used or refurbished unit, also verify the actual condition and whether the unit has been tested in the applicable VCE equipment.
Is 001-4130-03 still a current Brooks Automation product?
The public records located for this search primarily treat it as a legacy equipment spare rather than presenting it as a current mainstream Brooks catalog product. Procurement should therefore focus on exact identification and equipment compatibility rather than assuming current-production interchangeability.
