Eaton XV-303-15-C00-A00-1B is an advanced industrial Human Machine Interface (HMI) from the Eaton XV300 series, designed for modern machine control, visualization, and operator interaction applications. It combines a high-resolution touchscreen display, powerful embedded computing capability, and flexible industrial communication interfaces in a compact panel-mounted device. As an advanced HMI terminal, XV-303-15-C00-A00-1B provides operators with real-time visualization of machine status, process parameters, alarms, trends, and diagnostic information, enabling efficient monitoring and control of automated systems.
Eaton XV-303-15-C00-A00-1B features a 15.6-inch widescreen color touchscreen and belongs to the XV300 advanced HMI platform. The device is optimized for integration with PLCs, industrial controllers, drives, and automation networks through Ethernet and serial communication interfaces. The unit supports Eaton Galileo visualization software, allowing engineers to create intuitive graphical interfaces for industrial machines and production systems.
Eaton XV-303-15-C00-A00-1B is positioned as a high-performance operator interface solution for machine builders and system integrators requiring reliable visualization, flexible communication, and industrial-grade durability. Its fanless design, capacitive multi-touch technology, wide viewing display, and robust enclosure make XV-303-15-C00-A00-1B suitable for manufacturing equipment, packaging systems, material handling systems, and process automation applications where efficient human-machine interaction is essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | XV-303-15-C00-A00-1B |
| Manufacturer | Eaton |
| Product Type | Advanced Human Machine Interface (HMI) |
| Series | XV300 |
| Display Size | 15.6 inch |
| Display Resolution | 1366 × 768 pixels |
| Display Type | TFT color display with capacitive multi-touch |
| Touch Technology | Projected capacitive touchscreen (PCT) |
| Operating System | Windows Embedded Compact 7 Pro |
| Visualization Software | Eaton Galileo |
| Ethernet Interface | 2 × Ethernet 10/100 Mbps |
| Serial Interface | RS-232 / RS-485 |
| USB Interface | USB Host / USB Device |
| CAN Interface | CANopen / easyNet support |
| Supply Voltage | 24 VDC |
| Power Consumption | Industrial low-power design |
| Front Protection | Industrial front panel design |
| Mounting Type | Panel mounting |
| Communication Function | PLC and automation network integration |
| Compliance | RoHS compliant, EN 61000-6-4 |
XV-303-15-C00-A00-1B
Main Features and Advantages
Eaton XV-303-15-C00-A00-1B provides a powerful and flexible visualization platform for industrial automation applications. Compared with traditional operator panels, XV-303-15-C00-A00-1B integrates advanced processing capability, multiple communication interfaces, and modern touchscreen operation into a single industrial device, reducing the need for additional visualization hardware.
One of the key advantages of Eaton XV-303-15-C00-A00-1B is its large 15.6-inch touchscreen display. The widescreen format provides excellent visibility for complex machine layouts, process graphics, alarm lists, trend charts, and diagnostic screens. The capacitive multi-touch technology enables intuitive operation similar to modern consumer devices while maintaining industrial reliability.
The communication flexibility of XV-303-15-C00-A00-1B makes it suitable for integration into diverse automation architectures. With dual Ethernet interfaces, RS-232, RS-485, USB, and CAN communication capabilities, the HMI can connect with PLC systems, industrial controllers, drives, and peripheral devices. This allows system designers to implement efficient data exchange and centralized machine monitoring.
Eaton XV-303-15-C00-A00-1B supports Eaton Galileo visualization software, providing engineering teams with a convenient environment for designing operator interfaces. Users can create graphical process displays, alarm management functions, recipe handling screens, maintenance pages, and machine diagnostic interfaces according to application requirements.
The industrial design of XV-303-15-C00-A00-1B ensures reliable operation in demanding environments. The rugged touchscreen surface, fanless construction, and optimized thermal design reduce maintenance requirements and improve long-term operational stability.
Another important benefit of Eaton XV-303-15-C00-A00-1B is its ability to simplify machine architecture. By combining visualization and communication functions in one compact terminal, engineers can reduce cabinet space requirements and improve overall system integration efficiency.
The device is particularly valuable for OEM machine builders because it provides a standardized HMI platform that can be reused across different machine models. Its flexible communication options allow easy adaptation to different PLC brands and automation configurations.
With high visibility, flexible connectivity, industrial reliability, and powerful visualization capability, Eaton XV-303-15-C00-A00-1B is an effective solution for modern automation and machine control applications.
Applications
Eaton XV-303-15-C00-A00-1B is widely used in industrial automation systems requiring advanced operator visualization and machine control functions. In manufacturing environments, XV-303-15-C00-A00-1B is commonly installed on production machines to display operating parameters, production status, alarms, and maintenance information.
In packaging and material handling industries, Eaton XV-303-15-C00-A00-1B provides operators with real-time control interfaces for conveyors, filling machines, sorting systems, and automated assembly equipment. The large touchscreen allows operators to easily monitor multiple process variables and adjust machine settings.
Machine builders use XV-303-15-C00-A00-1B as a standard HMI platform for customized equipment such as CNC machines, printing systems, robotic workstations, and special-purpose automation equipment. Its communication flexibility simplifies integration with different PLC platforms.
In process automation environments, Eaton XV-303-15-C00-A00-1B can serve as a local operator station for pumps, motors, compressors, and auxiliary control systems. The device enables visualization of process data and provides access to diagnostic information for maintenance personnel.
Water treatment plants, energy systems, and infrastructure automation projects also benefit from XV-303-15-C00-A00-1B where reliable local monitoring and control are required.
Typical application areas include:
- Machine automation systems
- Packaging equipment
- Production lines
- Robotics and assembly systems
- Material handling equipment
- Process monitoring systems
- Pump and motor control stations
- OEM automation solutions
- Industrial control cabinets
