Description
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Eaton |
| Model | XV-440-12TSB-1-10 |
| Article Number | 139911 |
| Product Family | XV400 |
| Display | 12.1-inch TFT color |
| Resolution | 800 × 600 SVGA |
| Touch Technology | Infrared |
| Colors | 65,536 or 256 |
| CPU | 32-bit RISC, 400 MHz |
| DRAM | 64 MB |
| Flash | Approx. 1.5 MB available |
| NVRAM | Approx. 32 KB |
| Operating System | Windows CE |
| Nominal Supply | 24 VDC SELV |
| Permitted Supply | 20.4–28.8 VDC |
| Ethernet | 10/100Base-TX |
| RS232 | 1 × |
| CAN | 1 ×, galvanically isolated |
| USB | 2 × USB Host + 1 × USB Device |
| CompactFlash | 2 × Type I/II |
| Communication Module Slots | 2 |
| Typical Heat Dissipation | 32 W |
| Front Protection | IP65 |
| Rear Protection | IP20 |
| Dimensions | Approx. 361 × 279 × 93 mm |
| Recommended Cutout | Approx. 344 × 262 mm |
| Weight | Approx. 4.5 kg |
The XV400 documentation confirms the 12.1-inch SVGA display, infrared touch, 24 VDC supply, 64 MB DRAM, dual CompactFlash slots, two communication-module slots, and integrated Ethernet/RS232/CAN/USB interfaces.
Product Introduction
Eaton XV-440-12TSB-1-10 Industrial HMI
The Eaton XV-440-12TSB-1-10 is a 12.1-inch XV400 operator panel intended for machine and plant visualization. It uses an infrared touch interface over a laminated safety-glass front and provides an 800 × 600 TFT display with Ethernet, RS232, CAN and USB connectivity.
The unit is more than a basic display terminal. Its Windows CE platform, CompactFlash storage, communication-module slots and optional PLC capability allow it to serve as part of an HMI-PLC control architecture. The PLC function can be added through Eaton’s LIC-PLC-MXP-MEDIUM license.
XV-440-12TSB-1-10
Application Scenarios & Field Pitfalls
Engineering Pain Point
The important distinction with the XV-440-12TSB-1-10 is the infrared touch system.
It is easy to confuse this unit with the visually similar XV-430-12TSB-1-10. Both are 12.1-inch, 800 × 600 XV400 panels, but the XV-440 uses infrared touch while the XV-430 uses resistive touch. Eaton assigns different article numbers: 139911 versus 139909.
Typical Applications
- Machine automation: Operator screens, alarms, recipes and machine-status visualization.
- Production equipment: Local HMI for PLC-controlled manufacturing systems.
- Process machinery: Display and control of operating parameters and diagnostic information.
- Legacy XV400 installations: Replacement of existing 12.1-inch infrared-touch panels where the original project and communication configuration are retained.
Technical Pitfalls to Avoid
- Do not substitute XV-430 for XV-440 based on display size.
The XV-430-12TSB-1-10 uses resistive touch, while the XV-440-12TSB-1-10 uses infrared touch. The touch technology affects both operator behavior and the physical interface configuration. - Keep the PLC license separate from the hardware identification.
Eaton specifies that the PLC function is user-installable through LIC-PLC-MXP-MEDIUM, article 140390. A replacement display does not automatically mean that the existing PLC application and license configuration will be present. - Protect the infrared touch frame from contamination.
Eaton documentation notes that infrared-touch equipment requires regular cleaning of the IR frame. Dirt or contamination can interfere with touch detection. - Check sunlight exposure.
Eaton’s installation guidance specifically warns that direct sunlight can interfere with the infrared touch sensor. This matters when replacing an older panel in a machine enclosure that has changed location or cabinet layout. - Verify the mounting cutout.
The XV400 12.1-inch version uses a recommended flush-mounting cutout of approximately 344 × 262 mm. Do not assume that every 12-inch industrial HMI uses the same cabinet opening. - Check communication cards and CompactFlash configuration.
The provides two CompactFlash slots and two slots for communication modules. A replacement unit without the original project media or required communication hardware may not restore the machine immediately.
Related Products
- XV-430-12TSB-1-10 — 139909
Closest functional comparison. It has the same 12.1-inch / 800 × 600 display class but uses resistive touch instead of infrared touch. It should not be treated as an automatic substitute. - XV-440-12TSB-1-20 — 139913
Same basic 12.1-inch infrared-touch platform, but with a front plate featuring four mounting holes. The cabinet mounting arrangement must be checked before substitution. - XV-440-12TSB-1-50 — 139915
12.1-inch infrared-touch version with a stainless-steel front. It provides a different front construction for applications requiring stainless-steel equipment surfaces. - XV-440-10TVB-1-10 — 139904
10.4-inch infrared-touch panel with 640 × 480 resolution. Similar architecture, but different display size and cabinet cutout. - XV-460-12TSB-1-10 — 169824
Another 12.1-inch configuration. The exact hardware and application configuration should be compared before using it as a replacement. - XV-460-15TXB-1-10 — 139916
15-inch infrared-touch panel with 1024 × 768 resolution. Larger display and different mechanical dimensions make it unsuitable as a simple drop-in replacement. - LIC-PLC-MXP-MEDIUM — 140390
Optional PLC license associated with the medium-class HMI-PLC configuration. Important when the existing XV-440 installation uses onboard PLC functionality.
Procurement note: Specify Eaton XV-440-12TSB-1-10, Article No. 139911, 12.1-inch infrared-touch HMI. For a production replacement, verify the touch technology, cabinet cutout, Windows CE/CompactFlash configuration, communication modules, PLC license, and existing HMI project. The closest-looking XV-430 version is not equivalent from a touch-interface standpoint.
