HIMA F6214 | 4-Channel Analog Input Module | Safety-Related Process Signal Acquisition
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | HIMA Paul Hildebrandt |
| Model | F6214 / F 6214 |
| Part number | 984621402 |
| Module type | Safety-related analog input |
| Number of channels | 4 |
| Current inputs | 0–20 mA, 4–20 mA |
| Voltage inputs | 0–1 V, 0–5 V, 0–10 V |
| Resolution | 12 bit |
| Input resistance | 1 MΩ |
| Current-input shunt | 50 Ω, 0.05%, 0.125 W |
| Transmitter supply | 20–25 V, up to 22 mA |
| Short-circuit current | 25 mA |
| Maximum load impedance | 900 Ω |
| Input filter | Approx. 10 ms |
| Maximum scan time | 100 ms for 4 channels |
| Basic error | 0.2% at 25°C |
| Operating error | 0.3% at 0 to +60°C |
| Electrical strength | 250 V against ground |
| Space requirement | 4 TE |
| Module supply | 5 VDC / 24 VDC |
| Field application | Safety-related process measurement |
The original F6214 technical data specifies a 0–1.06 V input range for the 1 V setting, representing approximately 6% overrange. The 50 Ω precision shunt is used for current measurement, while the module can supply two-wire transmitters.
Product Introduction
The HIMA F6214 is a four-channel safety-related analog input module designed to acquire voltage and current signals from industrial transmitters. Typical measurements include pressure, flow, level and other process variables represented by 4–20 mA or voltage signals. Its 12-bit conversion and safety-oriented input architecture make it a component of the analog measurement path in a HIMA safety control system.
Each of the four channels can be configured for the supported signal type, with the documented interface also providing transmitter power for two-wire current-loop devices. The approximately 10 ms input filter and 100 ms maximum scan time for four channels are important when evaluating the module against the timing requirements of an existing safety application.
F6215
Application Scenarios & Field Pitfalls — Engineer’s Perspective
Engineering Pain Point
The F6214 is often confused with later HIMA analog modules because current reseller databases use inconsistent descriptions. The documented hardware is specifically a 4-channel analog input module, not a digital I/O card, communication module, or power supply.
Typical Applications
- Pressure transmitters — acquisition of 4–20 mA process-pressure signals.
- Flow measurement — interfacing analog flow transmitters with safety logic.
- Level monitoring — transferring transmitter values into a safety controller.
- Voltage-output sensors — accepting supported 0–1 V, 0–5 V or 0–10 V signals.
Technical Pitfalls to Avoid
- Do not substitute based only on channel count. F6214 has specific voltage/current ranges, transmitter-supply characteristics and safety-system requirements. A modern four-channel AI card is not automatically equivalent.
- Check the loop load. The documented maximum load impedance is 900 Ω, while the module’s transmitter supply and short-circuit behavior must also be considered when several field devices share the system’s power architecture.
- Terminate unused channels correctly. HIMA documentation states that unused channels must be terminated. Leaving an unused input floating can produce diagnostic or measurement behavior that is different from the original installation.
- Verify the exact material number. Current listings associate with 984621402, but legacy HIMA hardware can appear under different ordering references in databases. Match the nameplate and system documentation before replacement.
- Do not use generic 24 VDC claims as the field-input specification. The module has internal 5 VDC/24 VDC operating requirements, while its field transmitter supply is separately specified. These should not be treated as the same electrical parameter.
Related Products
- HIMA F6215 — 8-channel analog input module; higher channel count and different hardware configuration.
- HIMA F6217 — separate safety-related analog input module; verify signal and system compatibility before substitution.
- HIMA F6220 — analog input module intended for thermocouple applications.
- HIMA F6705 — analog output/D/A conversion hardware rather than analog input.
- HIMA F6706 — safety-isolated D/A conversion module.
- HIMA F3236 — safety-related binary input module for discrete signals.
- HIMA F3320 — safety-related output module.
- HIMA F3422 — relay output module for discrete output applications.
Procurement Note
For a replacement, verify:
- Complete model:
- Material number: 984621402
- Hardware revision
- Existing HIMA rack and slot
- Four-channel wiring
- 4–20 mA versus 0–20 mA application
- Voltage-input range where applicable
- Two-wire transmitter power requirements
- Termination of unused channels
- Existing safety application and validation documentation
Database classification: HIMA = 4-channel safety-related analog input module, 12-bit, supporting 0/4–20 mA and 0–1/5/10 V signals with safety isolation.
