Description
Product Overview
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 is a digital hydraulic axis controller belonging to the Rexroth SYHNC100-NIB series of high-performance closed-loop control electronics. It is specifically developed for intelligent hydraulic motion applications, providing precise control of hydraulic axes, proportional valves, and servo-hydraulic systems. The SYHNC100-NIB-22A/W-24-P-D-E24-A012 combines advanced digital signal processing technology with hydraulic control algorithms to achieve accurate position, velocity, and force regulation in demanding industrial environments. The SYHNC100-NIB family is widely recognized as a solution for high-dynamic hydraulic applications requiring fast response and stable operation.
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 is designed as a programmable hydraulic motion controller capable of processing feedback signals from position sensors such as LVDT and incremental encoders while controlling hydraulic actuators through proportional or servo valves. The controller supports communication with higher-level automation systems through industrial fieldbus interfaces, enabling integration into modern PLC-based production environments. The SYHNC100-NIB-22A/W-24-P-D-E24-A012 provides a flexible architecture suitable for applications involving punching, forming, pressing, positioning, and other precision hydraulic processes.
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 represents an important control component for hydraulic automation systems where mechanical precision, repeatability, and production efficiency are critical. Through digital closed-loop regulation, integrated diagnostics, and reliable industrial design, the controller helps improve machine performance, reduce commissioning effort, and increase the operational availability of hydraulic equipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | SYHNC100-NIB-22A/W-24-P-D-E24-A012 |
| Manufacturer | Bosch Rexroth |
| Product Type | Digital Hydraulic Axis Controller |
| Product Series | SYHNC100-NIB / VT-HNC Series |
| Application | Closed-loop hydraulic motion control |
| Control Function | Position, velocity and force control |
| Power Supply | 24 VDC |
| Controller Type | Programmable digital controller |
| Feedback Inputs | LVDT / incremental position sensor interfaces |
| Communication Interface | PROFIBUS-DP |
| Fieldbus Type | PROFIBUS communication |
| Digital I/O | Digital input and output processing |
| Analog Interface | Hydraulic sensor and valve control interface |
| Control Axes | Multi-axis hydraulic control (configuration dependent) |
| Valve Control | Proportional / servo hydraulic valve control |
| Parameterization Software | WIN-PED engineering software |
| Installation Method | Control cabinet mounting |
| Operating Environment | Industrial automation environment |
| Application Temperature | Industrial temperature range |
SYHNC100-NIB-23W-24-P-D-E23-A012
Main Features and Advantages
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 provides a powerful digital control solution for hydraulic systems that require higher accuracy and dynamic performance than conventional hydraulic controllers. By replacing traditional analog regulation methods with programmable digital control, SYHNC100-NIB-22A/W-24-P-D-E24-A012 enables precise monitoring and adjustment of hydraulic actuator movement.
High-precision closed-loop control is the core advantage of Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012. The controller continuously receives feedback signals from position measurement devices and calculates correction values in real time, allowing hydraulic cylinders and actuators to achieve improved positioning accuracy, smoother movement, and better repeatability. This makes the module particularly suitable for forming equipment and precision hydraulic machinery.
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 supports flexible sensor integration, including LVDT and incremental measurement systems. This enables engineers to select suitable feedback technologies according to machine requirements. The controller can adapt to different hydraulic architectures while maintaining stable control performance.
Another important advantage of Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 is its communication capability. Through PROFIBUS-DP integration, the controller can exchange process data with PLC systems and higher-level automation platforms. This simplifies machine networking and allows hydraulic functions to become part of a complete automated production system.
The modular structure of Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 improves maintenance efficiency. Engineers can configure, diagnose, and adjust controller parameters through dedicated software tools, reducing commissioning time and simplifying troubleshooting.
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 is designed for harsh industrial environments involving vibration, electrical interference, and continuous operation. Its industrial-grade construction ensures reliable performance in production machinery where downtime must be minimized.
For machine builders and industrial users, Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 offers a combination of precise hydraulic control, communication flexibility, and long-term reliability, making it an effective solution for advanced hydraulic automation systems.
Applications
Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 is widely used in industrial hydraulic applications requiring accurate motion control and high repeatability. Its digital closed-loop architecture makes it suitable for machines where hydraulic movement must be precisely controlled according to programmed operating profiles.
In metal forming and punching equipment, Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 provides accurate control of hydraulic cylinders used for pressing, forming, and material processing. The controller helps maintain consistent force and position control, improving production quality and reducing mechanical stress.
In hydraulic press systems, the SYHNC100-NIB-22A/W-24-P-D-E24-A012 enables precise actuator coordination and supports complex movement sequences. This is valuable in applications requiring controlled acceleration, positioning accuracy, and repeatable production cycles.
Machine manufacturers also apply Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012 in specialized automation equipment such as cutting machines, forming systems, test benches, and heavy industrial machinery. The controller provides the flexibility required for customized hydraulic control solutions.
The module is also suitable for modernization projects where older hydraulic control systems need replacement with digital technology. By integrating Bosch Rexroth SYHNC100-NIB-22A/W-24-P-D-E24-A012, users can improve system performance without completely redesigning existing hydraulic equipment.
Typical application areas include:
- Hydraulic punching machines
- Metal forming equipment
- Press automation systems
- Servo-hydraulic test systems
- Industrial production machinery
- Machine tools
- Heavy manufacturing equipment
- Precision hydraulic positioning systems
- Automated forming technology
