Description
Product Overview
GE Intelligent Platforms IC800SSI228RD2-CE is a VersaMax series 8-channel isolated discrete input module designed for industrial automation and PLC-based control applications. It is used to collect ON/OFF status signals from field devices and transfer them to the PLC control system through the VersaMax I/O architecture. As a flexible digital input interface module, IC800SSI228RD2-CE provides reliable signal acquisition for sensors, switches, relay contacts, and other discrete devices commonly used in factory automation environments.
GE Intelligent Platforms IC800SSI228RD2-CE supports both sinking (NPN) and sourcing (PNP) input configurations, making it highly adaptable for different types of industrial sensors and control devices. The module operates with 24 VDC field signals and provides channel-to-channel and channel-to-bus isolation, improving system stability and protecting the PLC backplane from field-side electrical disturbances. Within the GE VersaMax automation platform, IC800SSI228RD2-CE serves as an important interface between physical equipment and the control logic executed by the PLC CPU.
GE Intelligent Platforms IC800SSI228RD2-CE is designed for compact, modular automation systems where space efficiency, flexible installation, and reliable operation are essential. It can be used as part of local I/O stations or distributed remote I/O architectures, supporting applications ranging from machine automation and packaging equipment to process monitoring and industrial equipment control. With its rugged industrial design, diagnostic capability, and compatibility with the VersaMax family, IC800SSI228RD2-CE provides an effective solution for modernizing and maintaining GE automation systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC800SSI228RD2-CE |
| Manufacturer | GE Intelligent Platforms (GE Fanuc / Emerson Automation Solutions) |
| Product Type | VersaMax Discrete Input Module |
| Series / Platform | VersaMax I/O System |
| Module Function | Digital signal acquisition / discrete input interface |
| Number of Input Channels | 8 isolated input channels |
| Input Type | Sinking (NPN) or sourcing (PNP) selectable |
| Rated Input Voltage | 24 VDC |
| Input Voltage Range | 19.2 to 30 VDC |
| Input Current | Approximately 6 mA per channel at 24 VDC |
| Isolation Voltage | 500 VAC channel-to-channel and channel-to-bus |
| Input Response Time | Less than 1 ms typical |
| Field Connection | Removable screw terminal block |
| Module Power Supply | 5 VDC from VersaMax backplane |
| Field Power | External 24 VDC supply required |
| Diagnostic Function | Individual channel LED status indication |
| Operating Temperature | 0°C to 60°C |
| Installation Method | VersaMax rack / DIN rail mounting system |
| Certifications | CE, cULus, RoHS compliant |
IC800SSI228RD2-CE
Main Features and Advantages
GE Intelligent Platforms IC800SSI228RD2-CE provides a reliable and flexible digital input solution for industrial automation systems. Its most significant advantage is the selectable sinking and sourcing input capability, allowing engineers to connect different types of field devices without requiring separate module versions. This flexibility simplifies system design, reduces spare inventory requirements, and improves maintenance efficiency.
The 8-channel isolated input design of IC800SSI228RD2-CE improves electrical reliability in industrial environments. Each input channel is protected from external electrical interference, while the isolation between field signals and the PLC backplane helps reduce the impact of voltage fluctuations, wiring faults, and electrical noise generated by motors, drives, and switching equipment.
GE Intelligent Platforms IC800SSI228RD2-CE offers fast and accurate signal acquisition with a typical response time of less than 1 ms. This allows the module to capture rapid changes from sensors, limit switches, proximity detectors, and machine control devices. The high-speed input response makes IC800SSI228RD2-CE suitable for automation applications requiring precise sequence control and real-time machine monitoring.
Another important feature of IC800SSI228RD2-CE is its compact VersaMax modular design. The module can be easily integrated into distributed I/O systems, helping reduce cabinet space requirements while maintaining high system scalability. Engineers can combine it with other VersaMax modules to create customized control architectures based on application requirements.
The diagnostic capability of GE Intelligent Platforms IC800SSI228RD2-CE improves troubleshooting efficiency. Individual channel status indicators allow technicians to quickly verify input conditions during commissioning and maintenance. This reduces downtime by simplifying fault identification and improving service response.
Due to its industrial-grade construction, IC800SSI228RD2-CE provides stable performance in manufacturing environments exposed to electrical interference, vibration, and continuous operation. Its compatibility with GE VersaMax controllers makes it a practical choice for both new automation projects and existing system replacement applications.
With flexible input configuration, reliable isolation, compact installation, and proven GE automation technology, IC800SSI228RD2-CE delivers a dependable digital input solution for industrial control systems.
Applications
GE Intelligent Platforms IC800SSI228RD2-CE is widely used in industrial automation systems requiring reliable acquisition of digital field signals. In manufacturing equipment, the module is commonly applied for monitoring pushbuttons, selector switches, safety interlocks, proximity sensors, limit switches, and machine operating states. By transferring these signals to the PLC system, IC800SSI228RD2-CE enables precise sequence control and automated production management.
In packaging, material handling, and assembly machinery, GE Intelligent Platforms IC800SSI228RD2-CE provides high-speed detection of product position, actuator status, and equipment feedback signals. Its fast response capability allows automation systems to react quickly to changing machine conditions and improve production efficiency.
The module is also suitable for process automation applications such as water treatment systems, HVAC equipment, utility skids, and industrial monitoring stations. In these systems, IC800SSI228RD2-CE collects discrete status information from pumps, valves, alarms, and auxiliary equipment, providing essential feedback for PLC-based control strategies.
For OEM machine builders, GE Intelligent Platforms IC800SSI228RD2-CE offers a compact and flexible I/O solution that simplifies control cabinet design. Its support for both NPN and PNP devices allows integration with various sensor technologies used worldwide.
The module is also frequently used in maintenance and modernization projects involving existing GE VersaMax systems. Replacing older or damaged digital input modules with IC800SSI228RD2-CE allows users to restore system functionality while maintaining compatibility with existing PLC hardware.
Typical application fields include:
- Factory automation systems
- Packaging machinery
- Material handling equipment
- Machine tools
- Process control systems
- Water and wastewater facilities
- Energy automation systems
- OEM industrial equipment
