The IS210MACC1ACC is a high-reliability auxiliary control module manufactured by GE, belonging to the Mark VI series industrial turbine control system. Designed for heavy-duty power generation and industrial turbine equipment, it serves as an auxiliary signal acquisition and processing unit for speed, vibration and analog parameters, ensuring precise and stable operation of turbine control and protection systems.
1. High-precision Signal Processing：Optimized for turbine speed and vibration signal collection, with high-resolution signal sampling and filtering capabilities. It effectively eliminates industrial noise interference and ensures accurate acquisition of weak equipment operating signals.
2. Excellent System Compatibility：Fully compatible with GE Mark VI turbine control system, supporting seamless system integration and collaborative operation with various main control modules, perfectly matching power generation and industrial turbine control architecture.
3. Industrial-grade Anti-interference Design：Adopts reinforced electromagnetic shielding and anti-surge circuit design, with strong resistance to electromagnetic interference, voltage fluctuation and vibration impact, adapting to harsh power plant industrial environments.
4.Intelligent Self-diagnosis Function：Built-in comprehensive fault self-check program, which can real-timely monitor module operating status, signal channel abnormalities and circuit faults, and feed back fault codes to the upper system for rapid troubleshooting.
5. Stable Continuous Operation：Designed for 24/7 long-term uninterrupted operation, with low failure rate and strong operational stability, meeting the high-reliability operation requirements of core power equipment.
6. Standard Modular Structure：Adopts compact rack-mounted modular design, supporting convenient on-site installation, disassembly and maintenance, and flexible system function expansion and upgrade.
7. Multi-signal Adaptability：Supports multiple analog and auxiliary frequency signal input types, covering conventional monitoring signal types of turbine and generator units, with wide application adaptability.
IS210MACC1ACC
Product Parameters
|
Item
|
Specification
|
|
Part Number
|
IS210MACC1ACC
|
|
Brand
|
GE (General Electric)
|
|
Product Type
|
Auxiliary Signal Control Module
|
|
Applicable System
|
GE Mark VI Turbine Control System
|
|
Core Function
|
Turbine speed signal, vibration signal and analog auxiliary signal acquisition, processing and transmission
|
|
Working Voltage
|
Standard industrial DC power supply
|
|
Operating Temperature Range
|
0℃ ~ +60℃
|
|
Storage Temperature Range
|
-40℃ ~ +85℃
|
|
Working Humidity
|
5%~95% Non-condensing
|
|
Installation Method
|
Standard Rack Mounting
|
|
Protection Performance
|
Overvoltage protection, overcurrent protection, electromagnetic interference resistance
|
|
Support Function
|
Real-time signal monitoring, system self-diagnosis, fault alarm, data transmission
|
|
Application Characteristics
|
24-hour continuous operation, high stability for power generation equipment
|
Product Usage Method
1. Pre-installation Inspection: Check the module appearance, circuit board and terminals for damage, oxidation or loose components. Confirm that the module model matches the GE Mark VI system specifications to ensure installation compatibility.
2. Static Protection Operation: Perform installation in a dry, dust-free and static-free industrial environment. Wear professional anti-static gloves and wrist straps to prevent static discharge from damaging internal precision chips and circuits.
3. Module Installation & Fixation: Power off the control rack system, insert the IS210MACC1ACC module into the designated standard slot, and tighten the fixing screws to ensure stable contact between the module and the rack backplane bus.
4. Signal & Power Wiring: Connect power supply lines, turbine speed sensor lines, vibration signal lines and communication lines in strict accordance with the official wiring manual. Check wiring accuracy to avoid wrong connection, short circuit or signal distortion.
5. System Configuration & Debugging: Power on the system, connect the dedicated configuration software, set signal sampling parameters, threshold values and communication parameters according to the actual operating requirements of the turbine unit, and complete parameter downloading and saving.
6. Function Verification Test: Start the system self-diagnosis program to check the module operating status and communication connection. Simulate equipment operating signals to verify the accuracy of signal acquisition and normal data transmission function.
7. Online Operation & Daily Maintenance: After debugging is qualified, put the module into long-term online monitoring operation. Regularly check module operating temperature, wiring tightness and signal stability, clean dust periodically, and back up system configuration data to ensure stable operation.
