GE DS200PCCAG5ACB Power Connect Card (PCCA) Product Description
Product Overview
GE DS200PCCAG5ACB is a Power Connect Card (PCCA) designed for the GE Mark V Speedtronic industrial drive control system. As a high-power drive interface board within the GE DS200 series, GE DS200PCCAG5ACB provides the critical electrical connection between the SCR power bridge and the drive control circuitry. The board uses pulse transformer technology to transmit SCR gate drive signals, enabling precise control of high-power semiconductor switching devices in GE industrial drive systems. It is mainly applied in high horsepower drive configurations where reliable power conversion and motor control performance are required.
The GE DS200PCCAG5ACB belongs to the GE Mark V DS200 Power Connect Card family and is identified by the functional acronym PCCA. Within the Mark V drive architecture, GE DS200PCCAG5ACB acts as an interface module between the low-voltage control electronics and the high-voltage SCR power section. The board receives firing commands from the control system and delivers isolated gate pulse signals to the SCR bridge, while also providing communication with the DCFB-type power supply board. This design allows accurate regulation of power flow to large industrial motors and electrical loads.
Designed specifically for high horsepower applications, GE DS200PCCAG5ACB is part of the G5 PCCA group used with GE Mark V J, K, and M frame drive systems. Compared with lower-power PCCA variants, GE DS200PCCAG5ACB eliminates onboard snubber circuits and attenuation strings, with these functions handled elsewhere in the drive system. The board provides multiple SCR gate pulse interfaces, configurable jumpers, and rugged industrial PCB construction, making it a reliable replacement component for maintaining legacy GE drive installations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | DS200PCCAG5ACB |
| Manufacturer | GE (General Electric) |
| Product Type | Power Connect Card (PCCA) |
| Product Series | GE Mark V DS200 Drive Control Series |
| Functional Acronym | PCCA |
| Main Function | SCR bridge gate drive interface and power connection |
| Application | High horsepower industrial drive systems |
| Compatible Frames | GE Mark V J, K, and M frame drives |
| SCR Interface | Pulse transformer isolated gate pulse output |
| SCR Gate Signal Channels | 12 plug connectors for forward/reverse gate pulses |
| Power Supply Interface | Compatible with DCFB-type power supply board |
| Maximum AX Voltage | 1500 V RMS |
| Snubber Circuit | Not installed on board |
| Attenuation String | Not included |
| Configuration Jumpers | JP1, JP2, WP3, WP4 |
| PCB Coating | Normal protective coating |
| Installation Method | GE drive cabinet board carrier mounting |
| Revision Level | Functional Rev A / Functional Rev C / Artwork Rev B |
DS200PCCAG5ACB
Application Areas
Industrial DC Drive Systems:
GE DS200PCCAG5ACB is widely used in high-power DC drive applications requiring precise SCR control and reliable power conversion. It supports large motors used in industrial production equipment, ensuring stable speed and torque regulation.
Power Generation Facilities:
Power plants use GE drive systems for auxiliary motors, pumps, fans, and mechanical equipment. DS200PCCAG5ACB provides the SCR bridge interface required for reliable operation of these critical drive systems.
Steel and Metal Processing:
Steel mills require high-performance drive systems for rolling mills, conveyors, and processing machinery. GE DS200PCCAG5ACB supports high horsepower motor control applications where accurate power regulation is essential.
Paper Manufacturing:
Continuous paper production lines rely on stable motor control for rollers, feeders, and process equipment. DS200PCCAG5ACB helps maintain reliable operation of GE drive systems used in these environments.
Mining and Heavy Industry:
Mining equipment often requires large electrical drives operating under severe conditions. GE DS200PCCAG5ACB provides dependable SCR control interface capability for heavy-duty motor applications.
Industrial Retrofit Projects:
For facilities operating GE Mark V drive systems, DS200PCCAG5ACB is commonly used during maintenance, refurbishment, and lifecycle extension projects to replace aging power interface boards while preserving existing control architecture.
