ABB 3BHB009183P0001 | High-Voltage Filter Capacitor | Medium-Voltage Drive Maintenance

Key Technical Specifications

The published product record also identifies HB009183P0001 as the older/replaced product ID.

Product Introduction

ABB 3BHB009183P0001 is a high-voltage filter capacitor intended for ABB ACS6000 medium-voltage drive equipment. Its specified electrical rating is 250 nF at 7400 VDC, making it a specialized power-electronics component rather than a general-purpose capacitor. Component listings associate this exact part number with ACS6000 drive assemblies and filter circuitry.

For maintenance teams, the important point is the voltage class and application-specific design. A capacitor with similar capacitance but a different voltage rating, construction, pulse capability, or physical interface should not be treated as an automatic substitute. The part should be matched against the drive BOM, cabinet documentation, and the installed capacitor’s nameplate before installation.

3BHB009183P0001

Application Scenarios & Field Pitfalls

Engineering Pain Point

High-voltage filter capacitors are exposed to electrical stress, switching transients, thermal cycling, and aging. When one fails in a medium-voltage drive, replacing it with a component selected only by capacitance can create a serious compatibility problem. The 7400 VDC rating is a critical identification parameter.

Typical Applications

• ABB ACS6000 medium-voltage drives — replacement of an original filter capacitor during scheduled maintenance.
• Large industrial motor drives — service work involving medium-voltage power conversion equipment.
• Process-industry drive systems — spare-parts replacement where maintaining the original filter network is important.
• Drive refurbishment projects — restoration of an existing ACS6000 power section using application-specific components.

The surrounding ACS6000 spare-parts listings include filter chokes, reactors, phase-module components, capacitors, and other high-power converter components, supporting the identification of this part as part of the drive power circuit rather than a control-system capacitor.

Technical Pitfalls to Avoid

1. Do not substitute by capacitance alone. A 250 nF capacitor with a lower voltage rating is not an acceptable equivalent simply because the capacitance matches.
2. Check the complete drive configuration. Confirm the exact frame, power section, filter arrangement, and installed component position before ordering.
3. Inspect the old component before replacement. Evidence of bulging, leakage, terminal damage, discoloration, or abnormal heating should trigger inspection of the surrounding filter and power circuit rather than a capacitor-only replacement.

Related Products

• 3BHB009181P0001 — ABB 5 µH / 2200 A air-cooled choke associated with the drive filter/power circuit.
• 3BHB009181P0002 — 5 µH / 3724 Arms di/dt-limiting inductor for related power circuitry.
• 3BHB009182P0001 — 12 µH / 1800 A filter choke used in the family.
• 3BHB009128P0001 — DC film capacitor rated 2 × 1600 µF, 2866 V, serving a different capacitor function.
• 3BHB009946R0001 — 10 µF / 3200 V film snubber capacitor; not a direct replacement for the 250 nF / 7400 V filter capacitor.
• 3BHL000986P0006 — 4 µF / 2800 VDC capacitor with 4500 V maximum rating; different electrical duty and rating.
• 3BHB007211R0106 — XV C768 AE106 current-measurement module used in an -related power section, not a capacitor substitute.

Procurement Check

For 3BHB009183P0001, the most important purchasing checks are 250 nF, 7400 VDC, exact ABB part number, physical terminal arrangement, and the specific drive configuration. The published ABB-related record lists the part as a spare part and identifies HB009183P0001 as the replaced product ID. Before installation, compare the supplied component against the existing nameplate and maintenance documentation. For a high-voltage drive capacitor, electrical equivalence without mechanical and application equivalence is not enough.
