Description
Product Overview
ELAU MC-4/11/10/400 is a high-performance servo drive module belonging to the ELAU PacDrive MC-4 series, designed for advanced multi-axis motion control applications in industrial automation systems. ELAU, which became part of Schneider Electric, developed the PacDrive platform specifically for synchronized servo motion applications such as packaging machinery, robotics, and high-speed production equipment. The MC-4/11/10/400 servo amplifier provides precise control of AC servo motors and is optimized for applications requiring high dynamic response, accurate positioning, and reliable continuous operation.
The ELAU MC-4/11/10/400 functions as a decentralized servo power amplifier within the PacDrive motion control architecture. It receives control commands from a PacDrive controller and converts three-phase AC power into controlled motor currents for servo motors. With a rated continuous current of 10 A, peak current capability up to 25 A, and support for 380–480 VAC supply systems, the MC-4/11/10/400 is suitable for demanding machine automation applications where multiple servo axes must operate with precise synchronization.
ELAU MC-4/11/10/400 provides a compact and efficient solution for machine builders requiring reliable motion control hardware. The unit integrates advanced servo regulation technology, feedback processing, and communication capability within a modular PacDrive system. Its robust industrial design enables stable operation in packaging lines, assembly machines, material handling equipment, and other automated production systems where motion accuracy and uptime are critical.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | MC-4/11/10/400 |
| Manufacturer | ELAU (Schneider Electric) |
| Product Type | Servo Drive / Servo Amplifier |
| Series | PacDrive MC-4 |
| Application | Multi-axis servo motion control |
| Rated Supply Voltage | 380–480 VAC ±10% |
| Control Voltage | 24 VDC |
| Rated Continuous Current | 10 A |
| Peak Output Current | 25 A (1 second) |
| Rated Motor Power | Approx. 6.9 kW |
| Output Voltage | 0–480 VAC |
| Output Frequency | Up to 600 Hz |
| Power Supply Frequency | 50/60 Hz |
| Motor Feedback | Servo encoder feedback interface |
| Communication System | PacDrive motion bus |
| Installation Type | Control cabinet mounting |
| Cooling Method | Forced air / integrated heatsink cooling |
| Dimensions | Approx. 69 × 310 × 260 mm |
| Weight | Approx. 3.6 kg |
| Protection Function | Overcurrent, overload, thermal monitoring |
MC-41110400
Main Features and Advantages
ELAU MC-4/11/10/400 is designed to provide precise and reliable servo motor control for high-performance automation equipment. As part of the PacDrive MC-4 family, MC-4/11/10/400 combines power electronics, motion regulation, and feedback management into a compact industrial servo amplifier, reducing cabinet space requirements while improving system integration efficiency.
High dynamic performance is one of the primary advantages of ELAU MC-4/11/10/400. The servo drive uses advanced current and speed control algorithms to regulate motor torque and position accurately. This allows machines to achieve fast acceleration, smooth deceleration, and precise synchronization between multiple servo axes.
The 10 A continuous current capability of MC-4/11/10/400 makes it suitable for medium-power servo applications. The drive can deliver short-duration peak current performance, allowing connected servo motors to handle rapid load changes, acceleration phases, and demanding mechanical movements without sacrificing control stability.
Another important advantage of MC-4/11/10/400 is its integration within the ELAU PacDrive automation environment. The servo amplifier works together with PacDrive controllers to provide coordinated multi-axis motion control. This architecture is especially beneficial for machines requiring synchronized movements, electronic camming, positioning control, and high-speed automation sequences.
ELAU MC-4/11/10/400 provides excellent machine-building flexibility. Its modular design allows multiple servo amplifiers to be installed within a common control cabinet, enabling scalable solutions from simple single-axis machines to complex multi-axis production systems.
The diagnostic capability of MC-4/11/10/400 helps improve maintenance efficiency. The drive monitors important operating parameters including current load, temperature status, communication condition, and motor feedback signals. These diagnostic functions allow engineers to identify faults quickly and reduce machine downtime.
The compact mechanical design of MC-4/11/10/400 provides advantages in modern machine construction where cabinet space is limited. The optimized dimensions and efficient thermal management contribute to reliable operation in industrial environments.
With accurate motion control, strong overload capability, PacDrive compatibility, and industrial reliability, ELAU MC-4/11/10/400 remains a valuable servo solution for demanding automation applications.
Applications
ELAU MC-4/11/10/400 is widely used in industrial automation systems requiring precise multi-axis servo control. In packaging machinery, MC-4/11/10/400 provides coordinated control of feeding systems, sealing mechanisms, filling stations, labeling units, and robotic handling modules where synchronization accuracy directly affects production quality.
In food and beverage processing equipment, ELAU MC-4/11/10/400 supports high-speed servo movements for dosing systems, wrapping machines, carton handling equipment, and automated packaging lines. The servo drive enables smooth operation and accurate positioning during continuous production cycles.
Machine manufacturers use MC-4/11/10/400 in OEM equipment requiring advanced motion functions. Applications include printing machines, assembly systems, pick-and-place equipment, and specialized production machinery where precise servo control is essential.
In robotics and material handling systems, MC-4/11/10/400 provides reliable motor regulation for positioning axes, conveyors, indexing mechanisms, and automated transport equipment.
The drive is also widely applied in retrofit and maintenance projects involving existing ELAU PacDrive installations. Replacing aging servo amplifiers with compatible MC-4/11/10/400 units allows users to extend equipment lifetime while maintaining original motion performance.
Typical application areas include:
- Packaging machinery
- Food processing equipment
- Printing and converting machines
- Robotics systems
- Assembly automation
- Material handling systems
- Pick-and-place machines
- Multi-axis motion platforms
- OEM production equipment
- Industrial automation systems
