Allen-Bradley 2711P-T6C20 | 5.7-inch Color Touchscreen HMI with FactoryTalk View Support

Allen-Bradley 2711P-T6C20 | 5.7-inch Color Touchscreen HMI with FactoryTalk View Support

  • Model: 2711P-T6C20
  • Brand: Allen-Bradley / Rockwell Automation
  • Series: PanelView Plus 6 Terminals
  • Core Function: Provides operator visualization, machine control interface, alarm display, and process monitoring for industrial automation systems.
  • Product Type: HMI Terminal / Operator Interface Panel
  • Key Specs:
    • 5.7-inch color TFT touchscreen display
    • Ethernet and RS-232 communication interfaces
    • 24 VDC or AC power options depending on suffix configuration
    • FactoryTalk View Machine Edition runtime support
Add To Quote
Category: SKU: Allen-Bradley 2711P-T6C20

Description

Key Technical Specifications

Parameter Value
Product Model 2711P-T6C20
Manufacturer Allen-Bradley / Rockwell Automation
Product Type PanelView Plus 6 HMI Terminal
Display Size 5.7-inch TFT color LCD
Display Type Color active-matrix TFT
Operator Input Touch screen
Resolution 320 × 240 pixels
Communication Ports Ethernet 10/100 Mbps, RS-232, USB ports
Communication Protocols EtherNet/IP, DF1, DH-485, Modbus TCP (application dependent)
Operating System Windows CE 6.0 (suffix dependent)
Runtime Software FactoryTalk View Machine Edition Runtime
Input Voltage 24 VDC nominal (DC models) / AC models available by suffix
Power Consumption Approx. 15 W maximum for 600 series DC configurations
Mounting Panel mount
Enclosure Rating NEMA Type 12/13/4X indoor use, IP66 front rating
Operating Temperature 0…55 °C
Storage Temperature -25…70 °C
Memory Internal application storage and RAM configuration dependent



Product Introduction



Allen-Bradley 2711P-T6C20 Product Introduction

Allen-Bradley 2711P-T6C20 is a PanelView Plus 6 operator interface terminal designed for industrial machine control and process visualization applications. It provides a color touchscreen interface for displaying process values, alarms, operator commands, and diagnostic information while communicating with PLC controllers through Ethernet or serial networks.

The value of Allen-Bradley 2711P-T6C20 is maintaining existing Rockwell automation installations where application screens, FactoryTalk View projects, and controller communication structures are already established. Before replacement, verify firmware revision, FactoryTalk View runtime compatibility, communication drivers, and the exact power suffix.

2711P-T6C20

Application Scenarios & Field Pitfalls (The Engineer’s Perspective)



Engineering Pain Point

A failed HMI can stop an operator from viewing alarms, changing machine parameters, or controlling production equipment even when the PLC is still running normally. This is common in packaging lines, assembly systems, and process skids where the HMI is the primary operator connection.

Replacing the hardware is usually the easy part. Restoring the correct application file, communication settings, and firmware version is where most commissioning delays occur.



Typical Applications

  • Manufacturing Automation – Machine operator panels for packaging equipment, assembly lines, and production cells.
  • Water and Wastewater – Local operator stations for pump control, treatment processes, and equipment monitoring.
  • Food and Beverage – Process skids, batching systems, and production line visualization.
  • Oil & Gas – Local control panels for packaged equipment, compressor systems, and utility skids.



Technical Pitfalls to Avoid

  1. Confirm Complete Catalog Number
    The base code 2711P-T6C20 does not define every hardware option. The final suffix determines operating system features, power type, and regional configuration. Verify the complete label before ordering.
  2. Match FactoryTalk View Runtime Version
    Older PanelView Plus projects may require specific runtime versions. Loading an application onto an incompatible firmware revision can create startup or display issues.
  3. Backup the Existing Application Before Replacement
    Do not assume the PLC contains the HMI project. Export the FactoryTalk View ME application and record communication settings before removing the original terminal.



Related Products

  • Allen-Bradley 2711P-T6C20D8
    PanelView Plus 6 600 color touch terminal with Windows CE standard features. Used for applications that do not require extended Windows CE functions.
  • Allen-Bradley 2711P-T6C20D9
    Similar PanelView Plus 6 600 touch terminal with extended Windows CE features and additional file viewer capabilities.
  • Allen-Bradley 2711P-T6C20A9
    AC-powered PanelView Plus 6 600 color touch terminal configuration. Suitable when cabinet AC supply is preferred.
  • Allen-Bradley 2711P-T6C20A8
    AC-powered PanelView Plus 6 version without extended features. Used in standard HMI applications.
  • Allen-Bradley 2711P-B6C20
    PanelView Plus 6 600 keypad/touch version. Suitable where operators require physical function keys together with touchscreen operation.
  • Allen-Bradley 2711P-K6C20
    PanelView Plus 6 600 keypad-based HMI option for applications requiring dedicated button inputs.
  • Allen-Bradley 2711P-RP6
    PanelView Plus 6 replacement logic module. Used when the display assembly is still serviceable but the internal computer module requires replacement.
  • Allen-Bradley 2711P-RDT6C
    Replacement display module for PanelView Plus 6 600 color touchscreen terminals.
