Stucke SYMAP-BCG is a multifunctional digital protection relay and Power Management System (PMS) controller designed for generator protection, busbar management, synchronization control, and energy system automation applications. Developed by Stucke Elektronik, SYMAP-BCG belongs to the SYMAP family of advanced digital protection devices and combines generator protection functions, power management logic, diesel/gas engine control, and programmable automation capabilities into a single compact industrial controller. It is widely used in marine power systems, offshore platforms, distributed generation plants, and industrial energy networks requiring reliable electrical protection and intelligent power control.
Stucke SYMAP-BCG integrates multiple functions traditionally handled by separate protection relays, PLC controllers, synchronizers, and power management devices. The unit continuously measures generator voltage, current, frequency, power, and power factor while executing protection algorithms such as overcurrent, reverse power, over/under voltage, over/under frequency, and generator fault monitoring. Through integrated PMS functionality, SYMAP-BCG can perform automatic generator start/stop control, load sharing, load shedding coordination, and bus-tie management, reducing system complexity and improving operational reliability.
Stucke SYMAP-BCG is designed for medium-voltage and low-voltage power generation systems where high availability and flexible configuration are required. With communication interfaces including Modbus, Profibus, CAN bus, and optional IEC 61850 capabilities, the controller can be integrated into modern SCADA, DCS, and ship automation systems. Its compact stainless-steel housing, strong EMC performance, programmable logic functions, and comprehensive diagnostic features make SYMAP-BCG a reliable solution for critical electrical infrastructure.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | SYMAP-BCG |
| Manufacturer | Stucke Elektronik |
| Product Type | Digital Generator Protection Relay / Power Management Controller |
| Product Series | SYMAP Series |
| Main Function | Generator protection, PMS control, bus-tie management |
| Application | Medium and low voltage generator systems |
| Power Supply | 12–36 VDC |
| Measurement Inputs | 3-phase voltage, 3-phase current, frequency, power measurements |
| Protection Functions | Overcurrent, reverse power, voltage, frequency, differential protection options |
| Control Functions | Generator start/stop, synchronization, load sharing, load shedding |
| Digital Inputs | Configurable binary inputs |
| Relay Outputs | Configurable protection and control outputs |
| Analog Interfaces | 4–20 mA inputs/outputs (option dependent) |
| Communication Interfaces | Modbus RTU/TCP, Profibus DP, CAN bus, IEC 61850 option |
| Programming Function | Integrated PLC logic |
| Display Interface | Graphic LCD display with LED indicators |
| Installation Type | Panel mounting |
| Housing Material | Stainless steel EMC-resistant enclosure |
| Operating Environment | Industrial / marine environment |
| Protection Application | Generator, feeder, busbar and power system protection |
SYMAP-BCG
Main Features and Advantages
Stucke SYMAP-BCG provides an integrated approach to electrical power management by combining protection, control, and monitoring functions in a single intelligent device. This architecture eliminates the need for multiple standalone controllers and reduces wiring complexity, engineering effort, and maintenance requirements in generator-based power systems.
Integrated generator protection is one of the main advantages of SYMAP-BCG. The device continuously evaluates electrical parameters and provides fast protective responses against abnormal operating conditions. Functions such as overcurrent protection, reverse power protection, voltage supervision, frequency monitoring, and optional differential protection help protect generators and associated electrical equipment from damage.
The Power Management System functionality of SYMAP-BCG enables intelligent control of multi-generator installations. The controller can coordinate generator synchronization, automatic load distribution, standby generator operation, and load shedding strategies. This allows power systems to maintain stable operation during changing load conditions and improves fuel efficiency in generator-based networks.
Another important advantage of SYMAP-BCG is its programmable automation capability. The integrated logic functions allow engineers to customize control sequences without requiring an external PLC for many applications. Users can configure interlocks, alarms, operational sequences, and customized control strategies according to specific plant requirements.
Communication flexibility makes SYMAP-BCG suitable for modern automation architectures. The controller supports multiple industrial communication protocols, allowing connection with supervisory systems, ship automation systems, SCADA platforms, and distributed control systems. This enables centralized monitoring and efficient management of electrical assets.
The rugged construction of SYMAP-BCG provides reliable operation in demanding industrial environments. The compact stainless-steel enclosure improves electromagnetic compatibility and allows installation in control panels with limited space. Its high integration level reduces system footprint while maintaining comprehensive functionality.
For marine and offshore applications, SYMAP-BCG offers particular advantages by combining generator protection, PMS functions, and automation control in one device. This reduces the complexity of electrical switchboards and improves system availability in applications where power reliability is critical.
With advanced protection algorithms, integrated energy management, flexible communication, and programmable control functions, Stucke SYMAP-BCG provides a complete intelligent solution for modern generator and power distribution systems.
Applications
Stucke SYMAP-BCG is widely used in electrical power systems where generator protection, power management, and automation control are required. In marine applications, SYMAP-BCG is commonly installed in shipboard power management systems to control generator synchronization, load sharing, bus-tie operation, and electrical protection functions.
Offshore platforms use SYMAP-BCG to manage multiple diesel generators and maintain stable power supply for drilling equipment, production systems, accommodation facilities, and safety systems. The integrated PMS functions help optimize generator operation and improve fuel efficiency.
In industrial power plants, SYMAP-BCG provides generator protection and automation control for distributed generation systems, standby power plants, and cogeneration facilities. The device enables reliable coordination between generators and electrical distribution networks.
Power stations and energy facilities use SYMAP-BCG for monitoring and protecting synchronous generators, ensuring fast response to electrical faults and abnormal operating conditions. The controller can be integrated with SCADA and higher-level automation systems for centralized operation.
Renewable hybrid energy systems and microgrid applications can also utilize SYMAP-BCG where generator coordination and intelligent power distribution are required. Its flexible communication and programmable functions allow adaptation to different energy architectures.
Typical application areas include:
- Marine generator systems
- Offshore platforms
- Power management systems (PMS)
- Diesel generator plants
- Gas generator systems
- Industrial power stations
- Microgrids
- Distributed energy systems
- Ship automation systems
- Electrical switchgear protection
