  • Model: DS200SDC1OAEB
  • Manufacturer: General Electric (GE) — exact OEM identification should be confirmed from the board nameplate.
  • Product Family: DS200 series
  • Product Type: DS200-series circuit board/module; exact function requires verification.
  • Core Function: Exact function cannot be reliably established from the available documentation.
  • Platform: Likely associated with a legacy GE control-system architecture, but the exact host platform should be confirmed.
  • Revision Information: The G1OAEB suffix should be treated as part of the complete identification.
  • Procurement Status: Exact part-number verification recommended before purchase or substitution.
Add To Quote
Category: SKU: GE DS200SDC1OAEB

Description

Key Technical Specifications

Parameter Specification
Product Model DS200SDC1OAEB
Manufacturer GE
Product Family DS200
Board Function Not reliably verified
System Platform Verify from installed equipment
Input Voltage Not verified
Output Voltage Not verified
Communication Interface Not verified
I/O Channels Not verified
Connector Configuration Not verified
Hardware Revision Must be confirmed from board label
Firmware / PROM Must be confirmed from installed board
Operating Temperature Not verified
Mounting Verify cabinet/rack configuration
Replacement Equivalence Do not assume without OEM documentation



Product Introduction

The GE DS200SDC1OAEB appears to belong to the legacy GE DS200 board family, but the exact DS200SDC1OAEB designation could not be matched to a sufficiently reliable technical record during verification. Nearby DS200 SDC-family references exist, but assigning their specifications to this exact part number would create a real procurement and commissioning risk.

For an industrial spare, the complete board number is more important than the general DS200 family name. The physical PCB marking, functional acronym, artwork revision, connector population, PROM devices, and host cabinet location should all be recorded before treating another DS200 SDC-family board as a possible substitute.

DS200SDC1OAEB

Application Scenarios & Field Pitfalls — The Engineer’s Perspective

Engineering Pain Point

The main risk with DS200SDC1OAEB is misidentification. Legacy GE boards often have closely related base designations with different circuit functions or hardware revisions. A supplier describing a board only as a “DS200 SDC board” is not providing enough information to establish electrical compatibility.

Typical Applications

  • Legacy GE control-system maintenance: Potential -series spare application, subject to confirmation from the installed cabinet.
  • Board-level replacement: Appropriate only after matching the exact PCB identification and system position.
  • Obsolescence management: Useful as a candidate spare when the original board is difficult to source, provided equivalence is documented.
  • Troubleshooting: The original board should be identified from cabinet drawings and PCB markings before fault isolation proceeds.

Technical Pitfalls to Avoid

  1. Do not assume the SDC prefix defines the complete function. The exact part-number suffix and PCB identification must be checked.
  2. Do not substitute a nearby DS200SDC-family number solely because the board dimensions appear identical. Form factor does not establish electrical equivalence.
  3. Photograph the complete nameplate before removal. Record the full GE part number, artwork number, functional acronym, revision markings, and any PROM labels.
  4. Check the host cabinet documentation. The rack position and connected terminal boards can provide stronger evidence of the board’s actual function than reseller descriptions.
  5. Do not publish voltage, current, I/O-channel, or temperature ratings without verification. I found conflicting or insufficient public information for this exact designation, so those specifications should remain unconfirmed.
  6. Verify the character sequence carefully. DS200SDC1OAEB contains both the numeral 1 and the letter O in positions where transcription errors are possible. Compare the typed number directly with the PCB label.



Related Products

  • DS200SDCI-family boards — Nearby GE SDC references exist, but the exact electrical and functional relationship to DS200SDC1OAEB requires verification.
  • DS200SDCCG1AHD — A different board designation; do not treat it as a replacement without system-level verification.
  • DS200SDCCG4RGD — Another -family board with a different complete part number; physical similarity alone is insufficient for substitution.
  • DS200PPCBG1A — -series power-related board frequently encountered in legacy GE systems; different functional class and not a substitute for an unidentified SDC1OAEB board.
  • DS200TCCB-family boards — Mark V analog I/O boards with different functions and signal paths.
  • DS200TCEB-family boards — Mark V protective-interface boards; not interchangeable merely because they share the format.



Procurement and Replacement Note

For , I recommend treating the exact function as unverified until the physical board is checked. The minimum procurement package should include:

  • Complete PCB part number
  • Functional acronym printed on the board
  • Artwork/revision number
  • Photograph of the component side
  • Photograph of the connector side
  • PROM/firmware identification
  • Original cabinet/rack location
  • Host GE control-system model
  • Associated terminal-board part numbers

If you have a photo of the nameplate or PCB, that would be the most useful next step. With the board markings visible, the exact function, revision, connector layout, and related GE components can be distinguished without guessing.
