Description
EATON XVS-430-57MPI-1-10 HMI-PLC Operator Panel
Product Overview
The EATON XVS-430-57MPI-1-10 is a 5.7-inch XVS400 HMI-PLC operator panel designed for machine visualization, operator control, and industrial automation applications. Eaton specifies a color CSTN display with 320 × 240 pixel QVGA resolution, 256 colors, and a 4-wire resistive touch interface. The unit operates from 24 VDC and uses a metal enclosure and front plate for panel-mounted installation. Eaton assigns catalog number 139967 to this exact configuration.
The EATON XVS-430-57MPI-1-10 combines several communication interfaces in one compact operator terminal: 10/100Base-TX Ethernet, RS-232, PROFIBUS/MPI, USB Host, and USB Device. This makes the panel suitable for installations where an HMI must communicate with PLC equipment through an established fieldbus while also supporting Ethernet-based connectivity and local service functions. The XVS400 platform supports visualization and automation functions through Eaton’s software environment, with PLC capability available as an additional licensed function.
The EATON XVS-430-57MPI-1-10 uses Windows CE and requires a CompactFlash card for its operating environment. Eaton specifies 64 MB of DRAM and approximately 1.5 MB of available internal Flash storage. The front face is rated IP65, while the rear is IP20. These details are important when replacing an existing XVS400 panel because the physical hardware, CompactFlash configuration, application project, communication licenses, and PLC license can all affect whether the replacement reproduces the original machine behavior.
Product Introduction
The XVS-430-57MPI-1-10 belongs to Eaton’s XVS400 family of operator panels. Its design combines a compact touch display with industrial communication interfaces and optional PLC functionality.
The MPI/PROFIBUS interface is one of the defining characteristics of this model. For replacement applications, the complete model designation should be matched rather than selecting another 5.7-inch XVS400 solely because the mechanical dimensions appear similar.
Main Features and Advantages
5.7-Inch Color Display
The EATON XVS-430-57MPI-1-10 uses a 5.7-inch CSTN color display with 320 × 240 pixel QVGA resolution and 256 colors. Eaton specifies a visible display area of approximately 115 × 86 mm, typical brightness of 150 cd/m², and a typical contrast ratio of 35:1. The CCFL backlight is software dimmable, with a typical rated life of 50,000 hours.
The 4-wire resistive touch system is suited to industrial operator-panel applications where users may operate the interface with gloves, tools, or other non-capacitive input methods.
XVS-430-57MPI-1-10
PROFIBUS/MPI Connectivity
The integrated PROFIBUS/MPI interface allows the panel to communicate with compatible automation equipment without requiring a separate communication module. This is particularly relevant to established machine installations using MPI or PROFIBUS-based PLC communications.
The exact communication function available in an installed unit can depend on the software and license configuration, so the physical presence of the interface should not be treated as proof that every supported protocol is already activated.
Ethernet and Serial Communication
One 10/100Base-TX Ethernet interface and one RS-232 interface are integrated into the panel. Eaton also provides one USB Host and one USB Device interface.
This interface combination gives the XVS400 platform several options for engineering access, controller communication, application transfer, and service work. For legacy systems, however, existing communication drivers and project configuration should be documented before replacing the terminal.
Optional PLC Capability
The XVS400 is described by Eaton as an HMI-PLC platform with PLC functionality that can be retrofitted. Eaton identifies a PLC license for activating the PLC function, meaning that the hardware model itself should not be interpreted as proof that a particular unit has the PLC runtime enabled.
This distinction is important for spare-parts procurement. If the existing machine uses the XVS panel as both HMI and controller, the replacement must account for the PLC license and application software, not just the display hardware.
CompactFlash Storage
A CompactFlash card is required for the Windows CE operating environment. The panel provides one CompactFlash slot, while internal memory includes 64 MB DRAM and approximately 1.5 MB available Flash storage.
When replacing a failed unit, preservation of the original CompactFlash configuration can be critical. A replacement terminal with the correct hardware designation may still require restoration of the original operating environment, application, communication configuration, and licenses.
Panel-Mount Construction
The front of the XVS-430-57MPI-1-10 is rated IP65, while the rear is IP20. Eaton specifies a metal enclosure and front plate. Published dimensions are approximately 156 mm wide, 60 mm high, and 212 mm deep, with a weight of approximately 1.55 kg.
For replacement projects, verify the actual cabinet cutout and mounting arrangement rather than relying only on the external dimensions.
Key Technical Specifications
| Specification | EATON XVS-430-57MPI-1-10 |
|---|---|
| Manufacturer | EATON |
| Catalog Number | 139967 |
| Product Family | XVS400 |
| Product Type | HMI-PLC Operator Panel |
| Display Technology | CSTN color |
| Display Size | 5.7 inches |
| Resolution | 320 × 240 pixels |
| Format | QVGA |
| Number of Colors | 256 |
| Visible Area | 115 × 86 mm |
| Typical Brightness | 150 cd/m² |
| Typical Contrast | 35:1 |
| Backlight | CCFL |
| Backlight Life | Approx. 50,000 h |
| Touch Technology | 4-wire resistive |
| Supply Voltage | 24 VDC |
| Ethernet | 10/100Base-TX |
| RS-232 | 1 |
| PROFIBUS/MPI | 1 |
| USB Host | 1 |
| USB Device | 1 |
| Internal DRAM | 64 MB |
| Available Flash | Approx. 1.5 MB |
| CompactFlash | 1 × Type I/II |
| Operating System | Windows CE |
| PLC Function | Retrofittable by license |
| Front Protection | IP65 |
| Rear Protection | IP20 |
| Power Dissipation | 19 W |
| Width | Approx. 156 mm |
| Height | Approx. 60 mm |
| Depth | Approx. 212 mm |
| Weight | Approx. 1.55 kg |
Specifications are based primarily on Eaton’s product datasheet for catalog 139967.
Procurement and Replacement Considerations
For an existing machine, check the following before purchasing a replacement:
- Exact model: XVS-430-57MPI-1-10
- Catalog number: 139967
- PLC license: Determine whether PLC functionality is actually enabled on the existing unit.
- CompactFlash: Preserve the existing card and verify its operating-system/application contents.
- PROFIBUS/MPI: Record station address, communication parameters, and controller configuration.
- Ethernet: Record IP configuration and connected controller/software settings.
- Visualization software: Identify the original project and runtime environment.
- Mechanical fit: Confirm the cabinet cutout and mounting hardware.
- Front condition: For an older spare, inspect the touch layer, LCD, backlight, and front membrane before installation.
The most important procurement distinction is between hardware equivalence and application equivalence. Eaton explicitly states that PLC functionality and communication scope can be expanded through licenses, so a unit with the same physical model designation may not necessarily have the same licensed configuration as the installed panel.
Related XVS400 Models
- XVS-440-57MPI-1-10 — Catalog 139968
- XVS-450-57MPI-1-10 — Catalog 139969
- XVS-460-57MPI-1-10 — Catalog 139970
- XVS-430-10MPI-1-10 — Catalog 139972
- XVS-430-12MPI-1-10 — Catalog 139974
These models belong to the same broader XVS400 family but should not be treated as direct substitutes without checking display technology, communication configuration, dimensions, software, and licensing.
Frequently Asked Questions
What is EATON XVS-430-57MPI-1-10?
It is a 5.7-inch XVS400 HMI-PLC operator panel with a CSTN color display, resistive touch interface, Ethernet, RS-232, PROFIBUS/MPI, and USB interfaces. Its Eaton catalog number is 139967.
What voltage does the XVS-430-57MPI-1-10 use?
The unit is specified for 24 VDC operation.
Does this model support PROFIBUS?
Yes. Eaton specifies an integrated PROFIBUS/MPI interface.
Does it have Ethernet?
Yes. The unit provides one 10/100Base-TX Ethernet interface.
Does the panel include PLC functionality?
The XVS400 platform supports PLC functionality, but Eaton specifies that the PLC function can be retrofitted by license. Therefore, the installed license configuration should be verified when replacing an existing unit.
What type of display does it use?
It uses a 5.7-inch CSTN color display with 320 × 240 pixel QVGA resolution and 256 colors.
What is the Eaton catalog number?
The catalog number is 139967.
What should be checked before replacing one?
The critical checks are the exact model and catalog number, CompactFlash contents, PLC and communication licenses, PROFIBUS/MPI configuration, Ethernet settings, application project, and cabinet mounting dimensions.
