Description
VM600 MPC4 PNR200-510-070-113
Product Features
- The VM600 MPC4 is a high-performance machinery protection and monitoring processor module for the VM600 rack-based monitoring system.
- Supports multi-channel vibration, speed and process signal acquisition, real-time data processing and alarm logic judgment.
- Equipped with reliable fault diagnosis function, capable of continuous online equipment status monitoring.
- Provides standard industrial communication interfaces to realize data transmission with upper monitoring host and DCS system.
- Modular rack installation design, convenient for system expansion, maintenance and module replacement.
- Complies with industrial electromagnetic compatibility standards, suitable for harsh industrial site operating environments.
- Supports configurable alarm thresholds, event recording and historical trend data storage.
MPC4Mk2
• Height : 6U (262 mm, 10.3 in)
• Width : 20 mm (0.8 in)
• Depth : 187 mm (7.4 in)
• Weight : 0.42 kg (0.93 lb) approx.
IOC4Mk2
• Height : 6U (262 mm, 10.3 in)
• Width : 20 mm (0.8 in)
• Depth : 125 mm (4.9 in)
• Weight : 0.31 kg (0.68 lb) approx.
MPC4
Product Parameters
| Item | Specification |
|---|---|
| Model | VM600 MPC4, PNR200-510-070-113 |
| Product Type | Machinery Protection Processor Card |
| System Compatibility | VM600 rack monitoring system |
| Main Function | Signal processing, machinery protection logic, data communication |
| Installation Method | Rack-mounted plug-in module |
| Operating Temperature Range | 0 °C ~ +60 °C |
| Storage Temperature Range | -20 °C ~ +70 °C |
| Humidity Condition | 5%~95% non-condensing |
| Communication Protocols | Industrial standard communication protocols for host interconnection |
| Protection Function | Vibration overspeed alarm, fault status output, interlock signal support |
| Electromagnetic Compatibility | Meet industrial EMC standards |
| Dimensions | Standard VM600 module size |
Product Usage Method
- Confirm that the VM600 rack is powered off, insert the MPC4 module into the designated slot of the rack and lock it securely.
- Complete wiring connection according to system schematic, including power supply, sensor signal cables and communication cables.
- Power on the rack system, connect the configuration software to establish communication with the MPC4 module.
- Complete parameter configuration: set monitoring channels, measurement types, alarm thresholds and output logic.
- Download configuration parameters to the module and verify signal acquisition status.
- Enable online monitoring function, check real-time measurement data and alarm response performance.
- Regularly inspect module operating status, clean dust and back up configuration files.
Product Application Fields
- Thermal power generation units, steam turbines, generators
- Oil & gas compressors, pumps and turbo machinery
- Petrochemical rotating equipment monitoring systems
- Steel plant fans, rolling mill auxiliary rotating machines
- Hydroelectric generating sets
- Marine turbo machinery and power equipment
- Cement industry large fans and kiln driving equipment
- Paper industry high-speed rotating machinery
