Description
Product Overview
ABB 1TGE120010R1300 is identified as a control and protection unit intended for motor starting and operating control. Available industrial references describe the ABB 1TGE120010R1300 as a control module and motor starter/protection unit, with its primary role centered on controlling motor start, operation, and stop functions while providing protection against abnormal operating conditions.
The ABB 1TGE120010R1300 is therefore better treated as a dedicated motor-control assembly than as a conventional PLC CPU or generic DCS I/O module. The part is associated with motor and feeder control applications where starting and protective functions need to be integrated into the equipment architecture. One catalog reports a compact assembly approximately 53 mm wide, 125 mm high, and 260 mm deep, with a net weight of about 0.7 kg.
There is conflicting information online concerning the exact ABB product family and detailed protection/communication specifications. Some secondary listings associate this part with Emax 2, while other sources simply classify it as an ABB control module or motor starter. For procurement, the safest approach is to match the complete 1TGE120010R1300 part number and the physical hardware revision rather than relying on generic catalog specifications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Part Number | 1TGE120010R1300 |
| Product Type | Motor Control / Protection Unit |
| Functional Category | Motor Starter and Control Module |
| Primary Function | Motor starting, stopping, control and protection |
| Application | Industrial motor control |
| Associated Part | 1TGE102009R1001 |
| Reported Width | 53 mm |
| Reported Height | 125 mm |
| Reported Depth | 260 mm |
| Reported Net Weight | 0.7 kg |
| Protection Functions | Application-dependent; verify exact configuration |
| Communication | Verify exact hardware/configuration |
| Power Rating | Verify from nameplate/system documentation |
| Mounting | System/application dependent |
| Hardware Revision | Verify before replacement |
The dimensional and weight data above are specifically reported by an industrial catalog for 1TGE120010R1300.
Specification Caution
I would not publish fixed values for rated motor current, operating voltage, breaking capacity, communication protocol, or protection trip curves without the original ABB technical documentation for the exact revision.
Some secondary sources claim Modbus RTU, IEC 61850, overload protection, short-circuit protection, ground-fault protection, imbalance protection, and stall protection. Those functions are plausible for a motor protection/control architecture, but the available sources do not establish that every configuration of 1TGE120010R1300 provides all of them.
Main Features and Advantages
Motor Starting and Control
The principal role of 1TGE120010R1300 is associated with motor starting and operational control. It is intended to participate in the sequence governing motor start, normal operation, and stop conditions.
Integrated Protection
The unit is described as combining motor control with protective functions. In a properly configured installation, this type of architecture can reduce the amount of separate control hardware required around the motor starter.
Industrial Motor Applications
The part is relevant to industrial motor-driven equipment such as pumps, fans, compressors, conveyors, and other electrically driven machinery. The exact motor rating and protection settings must come from the installed system documentation rather than from a generic part-number lookup.
Compact Assembly
A reported package size of approximately 53 × 125 × 260 mm makes the unit suitable for compact control-panel integration.
Replacement Considerations
For an installed system, the most important replacement criteria are not just the part number. Verify:
- Motor voltage
- Motor full-load current
- Starter configuration
- Protection settings
- Auxiliary/control wiring
- Communication configuration
- Hardware revision
- Associated controller or protection system
1TGE120010R1300
Application Scenarios
- Motor starter panels: Control of motor starting and stopping.
- Industrial pumps: Motor control and protection for process pumps.
- Fans and blowers: Protection against abnormal motor operating conditions.
- Compressors: Motor-starting and protective control applications.
- Conveyor systems: Integrated motor control within industrial machinery.
- Process plants: Motor control assemblies connected to PLC/DCS supervisory systems.
- Maintenance spares: Exact replacement of installed legacy ABB motor-control hardware.
Engineer’s Guide: Field Pitfalls
WARNING 1 — Do not assume the published protection functions are universal
Online descriptions list overload, short-circuit, undervoltage, ground-fault, imbalance, and stall protection. However, the available documentation is not sufficient to confirm the exact protection package for every 1TGE120010R1300 configuration.
Field rule: Verify the protection function from the actual nameplate, manual, or system drawing.
WARNING 2 — Do not classify it as a PLC CPU
Although some secondary pages insert generic PLC language into the product description, the more consistent identification is a motor control/protection unit.
WARNING 3 — Verify the motor rating before replacement
A physically identical replacement can still be incorrectly configured for the customer’s motor.
Check:
- Rated voltage
- Rated current
- Starting method
- Motor power
- Protection settings
- Trip characteristics
WARNING 4 — Do not rely on the Emax 2 association without verification
One source explicitly associates the part with Emax 2, but other catalogs simply identify it as a control module or motor starter.
Procurement rule: Confirm the actual ABB system family from the equipment nameplate and drawings.
Frequently Asked Questions
What is ABB 1TGE120010R1300?
It is an ABB motor control and protection unit associated with motor starting and operational control. Multiple industrial sources identify it as a control module/motor starter unit.
Is 1TGE120010R1300 a PLC module?
No. It should not be treated as a conventional PLC CPU or I/O module. Its primary function is associated with motor starting, control, and protection.
What are the dimensions?
One industrial listing reports approximately 53 mm × 125 mm × 260 mm, with a net weight of approximately 0.7 kg.
These dimensions should still be checked against the physical unit before panel replacement.
Does it support Modbus?
Some secondary descriptions claim Modbus RTU, but I would not list Modbus as a confirmed native interface without verifying the exact hardware revision and associated communication equipment.
What motors can it control?
The appropriate motor rating cannot be determined safely from the part number alone. The motor’s voltage, current, starting method, and the specific configuration of the control unit must be matched.
What should be tested on a replacement?
For a used or refurbished 1TGE120010R1300, test:
- Physical condition.
- Correct part number.
- Hardware revision.
- Power/control circuit integrity.
- Motor-start command.
- Stop command.
- Protection/alarm functions.
- Auxiliary contacts.
- Communication, if installed.
- Functional operation with a representative motor-control setup.
Bottom line: The defensible classification for ABB 1TGE120010R1300 is motor control and protection/starter unit. The part identity is reasonably consistent across available sources, but detailed ratings and communication specifications should be verified against the actual ABB documentation before engineering substitution.
